HDMI MPEG4 AVC Network Encoder With Multi-protocol

Leírás

iENC This unit is designed especially for high channel density Distribution Video Engineering project which support rapid deployment, compatibility Up to 8/16/24 HD-MI inputs Simultaneously with MPEG-4 AVC/H.264 video encoding and LC-AAC or HE-AAC audio encoding. It’s ideal encoder, which can transfer the live program through the internet/LAN, and gives IP out over UDP (Unicast/Multicast), SRT, RTSP, RTMP, HTTP and HLS, and the output signals are to be received by PC, phone and other mobile terminals.

This solution is ideal for anyone looking for an easy and affordable way to support a large number of displays, such as a sports bar, house of worship, or digital signage. Multiple HD bridge units can be combined to create a headend that will support over 100 channels on your video network at each display. Depending on the number of programs you have, you can very flexibly choose a different number of coding channels.

This encoder can simultaneously encode N channels HD Audio & Video (8/16/24chs), It can generate 8/16/24 Channels SPTS.

Features

High density,modular 1-RU system capable of hosting up to 3 HD-MI Encoding input modules,each with 8 HD-MI channels
MPEG-4 AVC HP@L4 video compression
Feature to adjust the audio volume prior to encoding
Simultaneous outputs via 8* TS (each module)
IP Output over UDP (Unicast/Multicast), SRT, RTSP, RTP, RTMP, HTTP and HLS
Selectable the Value of PCR PID same as Video PID
Support VBR and CBR bitrate mode
PID Remapping & Filtering & CA FilterSupport LOGO,QR code,OSD insertion for every, All or Each module of local channel
One rack unit high density, low-power consumption, stackable
Easy-to-use web GUI
